    TSTLP SMT-ESE30 Ese Lightning Arrester Robust To Withstand Multiple Lightning Strikes

    Ask Lasest Price
    Brand Name : TSTLP
    Model Number : SMT-ESE30/SLC3D
    Certification : Patent Right / CE
    Price : Negotiable if good quantity
    Delivery Time : Around 7 working days upon receipt of payment
    Payment Terms : 100% TT / LC / Western Union / MoneyGram / WeChat Transfer / Alipay / Wanda Money Transfer / Cash ahead
    Supply Ability : 1000 pcs/month
    • Product Details
    • Company Profile

    TSTLP SMT-ESE30 Ese Lightning Arrester Robust To Withstand Multiple Lightning Strikes

    TSTLP SMT-ESE30 Ese Lightning Arrester Price More Competitive


    Features:

    • Patent No.2013300191363
    • Spanish standard UNE 21.186:2011 Paragraph C compliance
    • SMT-ESE30 early streamer emission air terminal shall be self-active when electrical field intensity rises Fully reliability, easy for installation
    • Robust to withstand multiple lightning strikes.
    • ISO 9001:2015 CertifiedManufacturing Process

    TSTLP ESE lightning ese lightning arrester works ?

    TSTLP SMT-ESE30 Ese Lightning Arrester Robust To Withstand Multiple Lightning Strikes


    • Technical Parameters
    BrandTSTLP
    ESE Lightning Arrester modelSMT-ESE30
    Patent NumAvailable as request
    Efficiency (ΔT μs)30
    Lightning current withstanding test Iimp100kA (normative test at 10/350μs waveform as standard requires)
    Lightning current withstanding Iimp≥ 200kA (10/350 μs)
    Capacity against wind speed≥144 kilometer/hour
    Dimension(Length:)418
    Approx net weight3000g
    Metal HousingSuperior Quality SS
    Technical StandardsNF C 17-102_2011 Annexe C
    UNE 21.186:2011 Paragraph C
    IEC 60060-1:2010 Part 1
    EN 60060-1:2010
    GB/T T16927.1-2011 Part 1;
    HS code for ese lightning arrester8535400000

    TSTLP SMT-ESE30 Ese Lightning Arrester Robust To Withstand Multiple Lightning Strikes


    • PROTECTION RADIUS of ESE lightning arrester (Calculation)

    The protection radius of TSTLP ese lightning arrester is related to its height (h) relative to the surface to be protected, to its efficiency and to the selected protection level

    for h ≥ 5 m;

    TSTLP SMT-ESE30 Ese Lightning Arrester Robust To Withstand Multiple Lightning Strikes

    and

    Rp = h × Rp(5)/5 for 2 m ≤ h ≤ 5 m

    Rp (h) (m): is the protection radius at a given height h

    h (m) : is the height of the ESE lightning arrester tip over the horizontal plane through the furthest point of the object to be protected

    r (m) : 20 m for protection level 1

    30m for protection level 2

    45m for protection level 3

    60m for protection level 4

    Δ (m) = ΔT x 106

    Field experience has proved that Δ is equal to the efficiency obtained during the ESE lightning arrester evaluation tests


    • Radius Protection of ese lightning arrester SMT-ESE30

    TSTLP SMT-ESE30 Ese Lightning Arrester Robust To Withstand Multiple Lightning Strikes


    • Real Installation photo

    TSTLP SMT-ESE30 Ese Lightning Arrester Robust To Withstand Multiple Lightning Strikes


    • FAQ

    1 - Are you just trader or ese lightning arrester manufacturer for above ?

    - ese lightning arrestor manufacturer


    Download PDF 2020 TSTLP ESE Lightning Rod Catalogue @ http://www.ese-lightningrod.comhttps://drive.google.com/file/d/1kEW-pWdJdlArVgfrHutq62k9HsVNcHq-/view?usp=sharing​


    PDF Datasheet Download - TSTLP SMT-ESE30.pdf
