    5kA / 10kA Type 3 Lightning Surge Arrester For TT / TN S Power Supply Systems

    Ask Lasest Price
    Model Number : TS-275M5RM
    Brand Name : TSTLP
    Certification : CE Compliance
    Price : Negotiable if good quantity
    Delivery Time : Around 7 working days upon receipt of payment
    Payment Terms : 100% TT / LC / Western Union / MoneyGram / WeChat Transfer / Alipay / Wanda Money Transfer / Cash ahead
    Supply Ability : 2000 sets/month
    • Product Details
    • Company Profile

    5kA / 10kA Type 3 Lightning Surge Arrester For TT / TN S Power Supply Systems

    TSTLP 5kA / 10kA Type 3 mov surge arrester for TT / TN S power supply systems

    (12V / 24V / 36V / 48V / 60V / 120V / 220V / 230V available to make as request)


    TSTLP TS-275M5RM Class D MOV Surge Arrester, designed according to IEC 61643-11; GB 18802.1;YD/T 1235.1 are as fine protection for electronic devices. For installation at LPZ 1-2 or higher, applied in Type 3 Surge Arrester for power supply systems (provide fine protection for single-phase power of low power supply system;e.g. icebox, air conditioner, photocopy, communication equipment, network equipment and so on.)


    • Technical Specification P1
    Model NumTS-275M5RM
    Rated voltage (max. continuous voltage)Uc275V~
    Normal CurrentIL16A
    Nominal discharge current (8/20)In5 kA(L-N); 5 kA(L+N-PE); In : 10 kA(total)
    Max. discharge current (8/20)Imax10 kA(L-N); 10 kA (L+N-PE); Imax: 20 kA(total)
    Voltage protection levelUp≤ 0.95 kV(L-N); ≤ 1.5 kV(L+N-PE)

    Technical Specification P2

    5kA / 10kA Type 3 Lightning Surge Arrester For TT / TN S Power Supply Systems


    • Features
    1. (1+1 circuit mode) mov surge arrester for TN-S/ TT system
    2. Green light indicates normal and red indicates fault
    3. Single-phase protection and with disconnector
    4. Remote signalling connector for fault indication
    • Installation Instruction

    5kA / 10kA Type 3 Lightning Surge Arrester For TT / TN S Power Supply Systems


    • Real Type 3 Surge Protector Real Installation Reference.

    5kA / 10kA Type 3 Lightning Surge Arrester For TT / TN S Power Supply Systems


    PDF Catalog Download - TS-275M5RM T3 SPD.pdf
